DC12V Switch Power Supply

High operating temperature up to 70C

AC input range selectable by switch

Forced air cooling by built-in DC Fan

Protections: short circuit / over load/ over voltage/ over temperature

 3 year warranty

LED Indicator for power on

Additional information

Output Voltage:

DC12V/24V

Input Voltage

AC110V-240V

Power

350W

DC12V Switch Power Supply

Switch power supply

SMPS (Switched mode power supply)

Detailes:

MODEL

GR-360-12

OUTPUT

DC VOLTAGE

12V

RATED CURRENT

30A

CURRENT RANGE

0 ~ 30A

RATED POWER

360W

PEAK LOAD(23.5CFM)

100.5W

RIPPLE & NOISE (max.) Note.2

150mVp-p

VOLTAGE ADJ. RANGE

13.5 ~ 16.5V

VOLTAGE TOLERANCE Note.3

±1.0%

LINE REGULATION

±0.5%

LOAD REGULATION

±1.0%

SETUP, RISE TIME

500ms, 30ms/230VAC          500ms, 30ms/115VAC at full load

HOLD UP TIME (Typ.)

80ms/230VAC          20ms/115VAC at full load

INPUT

VOLTAGE RANGE

90 ~ 264VAC          127 ~370VDC

FREQUENCY RANGE

47 ~ 63Hz

EFFICIENCY (Typ.)

83%

AC CURRENT (Typ.)

1.5A/115VAC          1A/230VAC

INRUSH CURRENT(Typ.)

COLD START 25A/115VAC          50A/230VAC

LEAKAGE CURRENT Note.7

Earth leakage current < 150£gA/264VAC , Touch current < 100 A/264VAC

PROTECTION

OVERLOAD

140 ~ 180% rated output power

Protection type : Hiccup mode, recovers automatically after fault condition is removed

OVER VOLTAGE

17.25 ~ 20.25V

Protection type : Shut down o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.

-20 ~ +70°C(Refer to “Derating Curve”)

WORKING HUMIDITY

20 ~ 90% RH non-condensing

STORAGE TEMP., HUMIDITY

-40 ~ +85°C, 10 ~ 95% RH

TEMP. COEFFICIENT

±0.03%/°C (0~45°C)

VIBRATION

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS

ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1 approved

WITHSTAND VOLTAGE

I/P-O/P:4KVAC     I/P-FG:2KVAC O/P-FG:1.5KVAC

ISOLATION RESISTANCE

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25°C/ 70% RH

EMC EMISSION

Compliance to EN55011 (CISPR11), EN55022 (CISPR22) Class B, EN61000-3-2,-3

EMC IMMUNITY

Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN60601-1-2, EN61000-6-2, EN61204-3, heavy industry level, EN61204-3 medical level, criteria A

OTHERS

MTBF

446.8K hrs min.      MIL-HDBK-217F (25°C)

DIMENSION

127*76.2*31mm (L*W*H)

PACKING

0.26Kg; 63pcs/16.3Kg/1.35CUFT

NOTE

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 ℃of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12″ twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.”

5. Length of set up time is measured at cold first start. Turning ON/OFF the power supply may lead to increase of the set up time.

6. Heat Sink HS1,HS2,HS3 can not be shorted.

7.Touch current was measured from primary input to DC output

8. Suitable for BF application with appropriate system consideration.
